InterVOLT ILSPCI121220G2 Gen II Power Conditioner: 10A 10.5-16VDCInput/12VDC 12-14.4VDC Output (Adjustable)

(No reviews yet) Write a Review
SKU:
ILSPCI121220G2
Condition:
New
Weight:
2.00 LBS
  • InterVOLT ILSPCI121220G2 Gen II Power Conditioner: 10A 10.5-16VDCInput/12VDC 12-14.4VDC Output (Adjustable)
  • InterVOLT ILSPCI121220G2 Gen II Power Conditioner: 10A 10.5-16VDCInput/12VDC 12-14.4VDC Output (Adjustable)
MSRP: $390.00
$349.97
— You save $40.03
Typically ships within 1-2 Business days. Please contact us for availability or for time sensitive orders.

Description

InterVOLT ILSPCI121220G2 Gen II Power Conditioner: 10A 10.5-16VDCInput/12VDC 12-14.4VDC Output (Adjustable)

The InterVOLT SPCi Maxi Series Gen II power conditioners is a cutting edge product known for resolving many of the issues associated with DC power in vehicles and vessels. They are in fact a converter, stabilizer, isolator and regulator all built into a single innovative package. These devices feature galvanic isolation with no common connectivity between the input and output via positive or negative conductors. This means peace-of-mind when connecting sensitive and often expensive, high-end electronic equipment to the output. Other benefits include elimination of line interference, greater protection, better regulation and improved performance.

The GEN II unit has digital over analogue topology which allows the installer/operator to control and monitor various functions and provides valuable feedback on the status of the connected load.

The GEN II units are  more compact due to multi-speed fan cooling and as a result no longer relies on convection for cooling.

Features:

  • Unique operator interface for control and monitoring
  • Galvanically isolated input to output – no common connectivity
  • Handy charge mode for charging an auxiliary battery (2 stage)
  • User adjustable output voltage from 12V to 14V (0.5V increments)
  • Diagnostic indicator: stand by mode, load on, short circuit, temperature
  • Remote operator control to turn unit on/off with signal current only
  • Multi function alarm output for fault and pre-emptive warnings
  • Temperature and speed controlled internal cooling fan (Vapo bearing)
  • Compact design and can be mounted vertically or horizontally
  • Heavy duty termination with separate, removable terminal cover
  • High quality assembly featuring marine grade hardware
  • Conformally coated printed circuit board assembly

Specifications:

Housing Finish/Material Anodized 6063 aluminum, ABS/PC , stainless steel hardaware
Certifications & Compliance CE-EMC, ROHS, Australian C-Tick
Class B
Input Voltage 10.5-16VDC (down to 9V during operation)
Dimensions 9.10" (230mm) x 1.17" (110mm) x 2.17" (55mm)
Warranty 2 Years
Output voltage 12.0-14.0VDC (adjustable in 0.5V increments)
Ingress Protection IP40
Load Rating 10A (continuous), Peak Load is 125%
Mounting Method Screws (vertical or horizontal surface)
Max Operating Temperature 122° F (50° C)
Standby Current 85mA (nominal)
Efficiency 91% nominal (load dependent)
Install Location Dry loaction, vertical or horizontal
Electrical Protections Transients, overload/short circuit, over temperature, over voltgae, reverse polarity, and more...
Approximate Ship Weight (lbs) 2
