Phasor Marine K4-21KW Standard Series Diesel Boat Generator

(No reviews yet) Write a Review
SKU:
K4-21.0KW
UPC:
K4-21.0KW
Availability:
Please contact us for availability
Weight:
776.00 LBS
Contact us for Boat Show Pricing: 619.222.9613

Description

PHASOR MARINE 21.0kW Marine Diesel Generator - K4-21.0KW


The Phasor Marine 21.0kW generator is one of the most popular marine diesel gensets for boats 45' - 70'. The unit outputs 175 amps on 120VAC at a low 1,800 RPM operating speed; powered by a Kubota V2403-M-E4BG 4 cylinder diesel engine.

Basic Specifications:

  • Dimensions: (LxWxH) 39.5"x 21.0"x 26.0" (With Hard Sound Enclosure 43"x24"x28.0")
  • Weight: 776bs
  • Operating Speed: 1,800 RPM (Less wear and tear compared to a 3,600RPM Genset)
  • Output Volts: 120/240
  • Output Amps: 175/87.5
  • Output Watts: 21,000
Features:
  • Engine:
    • Kubota Diesel Engine: V24030-M-E4BG - 4 Cylinder - 148.5cu.in. displacement - Naturally Aspirated/IDI
    • Single Bearing Direct Coupled Brushless Generator
    • Safety shutdown system for high coolant temp or low lube oil pressure
    • Air Intake Cleaner / Silencer
    • Stainless Steel Exhaust Elbow Cast
    • Stainless Steel 4-Point isolation mounts
    • Belt Guard
    • Awl-Craft 2000 Urethane Finish - Long Lasting Gloss - Color Retention
  • Electrical:
    • +/- 1% Solid-state voltage regulation
    • Single series circuit control system with no printed circuit boards - tinned wiring
  • Fuel System:
    • Electric Fuel Transfer Pump
    • Secondary 5 Micron Fuel Filter
    • USCG Approved fuel lines
    • Self Bleed Fuel System
  • Oil System:
    • Spin-on lube filter
    • Forged Brass Oil Drain Valve with Safety Lock
  • Cooling System:
    • Gear Driven Raw Water Pump
    • Molded blue silicone water hoses with Stainless Steel AWAB Clamps
    • Freshwater Double Pass Heat Exchanger - zinc anode inside
  • Phasor Marine Five Year Pleasure Craft Limited Warranty
Phasor also offers optional upgrades for the 21.0kW generator:
  • Remote Panels
    • Remote Start/Stop Panel WITHOUT hour meter, supplied with 20ft harness - 101-0092
    • Remote Start/Stop Panel With Four Gauges and 20ft harness - 101-0060
    • Remote Panel 10 ft extension harness - 101-0061
    • Remote Panel 20 ft extension harness - 101-0062
    • Relay Pak needs to be used with harnesses over 20ft -101-0333
  • Stainless Steel Drip Pan - 101-0056
  • Powder Coated Aluminum Drip Pan - 101-0302
  • Aluminum Sound Enclosure - 101-0232
  • 24 VDC Electric - 101-0070
  • Phasor Marine Spare Parts Kit - 101-0085
  • Three Phase Generator Wiring - 101-0067
Downloads Section: Phasor Standard Series K4-21.0 Generator Product Sheet [PDF] Phasor Marine 5 Year Warranty [PDF]
