NEXTGEN UCM2-5.5 5.5kw Ultra Compact Generator
Many boaters want a gen-set but have limited space aboard their craft. A new 5 kW diesel gen-set can solve this problem, as it boasts the shortest length of any 5 kW unit on the market.
- Comes with or without an enclosure
- Comes with the option for Ignition Protection
- NEXT Generations UCM 2-5.5 is perfect for mid-size vessels, or as a back-up for large vessels
- Mid speed operation provides low sound and vibration levels. Comparable sound levels to same k.w. heavy weight 1800 RPM sets
- Super efficient “Three Vortex Combustion System” provides greater power output and cleaner burning exhaust while reducing fuel consumption to a minimum
- Compact size & light weight make for an easy installation
- One side service provides easy maintenance
Product Features:
- Cupro - Nickel Heat Exchanger
- Water Cooled Exhaust Manifold
- Direct Driven Self Priming Sea Water Pump
- Stainless Steel Water Cooled Exhaust System
- Air Cleaner/intake Silencer
- Helical Offset Tooth Timing Drive System
- Oil pressure & water temperature safety shutdown
- 120/240 Volt Generator
- 12 volt electric fuel pump
- Extra resilient four point isolation mounts
- “Easy Drain” oil change kit
- Front side service
- Marine grade tinned wire Wire With Heat Shrink Terminals
- Remote start panel with hour meter and harness
- 3 Year Limited Warranty
Product Specifications:
- Dimensions
- 23" Long x 17" Wide x 20" High
- With Enclosure 25.5" Long x 20" Wide x 21" High
- Weight
- Without Enclosure 230lbs
- With Enclosure 270lbs
- Operating Speed: 2,800 RPM (Less wear and tear compared to a 3,600RPM Genset)
- Output Volts: 120/240
- Output Amps: 46/23
- Output Watts: 5,500
- Vertical, Water Cooled 4 Cycle diesel engine
| Number of Cylinders | 2 |
| Bore x Stroke (In) | 2.64 x 2.68 |
| Displacement (Cu. In.) | 29.23 |
| SAE net intermittent (HP/rpm) | 11.0 @ 2800 RPM |
| Combustion System | Three Vortex |
| Compression Ratio | 23:1 |
| Fuel injection Pump Type | Bosch MD Mini Pump |
| Nozzle Type | Bosch “throttle” type |
| Cooling System | Fresh Water Heat Exchanger |
| Lubricating System | Forced Lubrication w/filter |
| Fuel | #2 Diesel Fuel |
| Lubricating Oil | API Service CD or CE |
| Fresh Water capacity | 2.2 U.S. Quarts |
| Lubricating Oil Capacity | 1.O U.S. Quarts |
| Starting System | 12V Battery |
| Charging System | 10 AMP (Optional) |
| Fuel Line Diameter | 5/16" |
| Return Line Diameter | 1/4" |
| Raw Water Diameter | 5/8" |
| Exhaust Diameter | 1 1/2" |
Optional upgrades:
- Ignition Protection Certification
- Sound Enclosures
- Full Instrumentation Panel
- 20' or 30' Wire Harness
Downloads & Resources:
- NextGen 5.5 Generator Brochure [PDF]
- NextGen 5.5 Generator Manual [PDF]
- Tech Support: View Our Tech Support Page
Warranty Information
Seatech Marine Products is an authorized dealer for NEXTGEN Generators. This has a limited 3-year warranty from them.
