BayStar HP4600 Seal Kit with Glands for “H” Cylinders
OEM End Gland Seal Kit for BayStar Compact Front Mount Cylinders
The Dometic BayStar HP4600 Seal Kit is designed specifically for BayStar Compact Front Mount Cylinders with NPT-threaded “H” fittings, including models HC4645H, HC4647H, HC4648H, and HC4658H. This complete kit includes both port and starboard end glands, O-rings, shaft seals, wipers, and new socket screws—everything needed for a full gland rebuild.
This is the NPT-thread version of the HP4601 kit (which is for ORB-threaded -3 models).
Key Features & Benefits
- Complete Seal & Gland Replacement – Includes everything needed for a full end gland service
- Designed for H Cylinders – Use only with cylinders that have H part numbers
- Includes All New Hardware – Discard old screws as new socket head screws are included
- OEM-Grade Components – Meets or exceeds manufacturer standards
- Easy, Step-by-Step Installation – No special tools required beyond common hand tools
Compatible Cylinder Models
Cylinder Part # | Description |
---|---|
HC4645H | BayStar Compact Front Mount Cylinder (NPT) |
HC4647H | BayStar Compact Front Mount Cylinder (NPT) |
HC4648H | BayStar Compact Front Mount Cylinder (NPT) |
HC4658H | BayStar Compact Front Mount Cylinder (NPT) |
Kit Contents (HP4600)
Item | Qty | Description |
---|---|---|
— | 2 | Wiper |
— | 2 | Shaft Seal |
— | 2 | O-Ring |
— | 4 | BHCS 1/4" NC x 1.5” SS Screws |
— | 1 | Gland, Port Side |
— | 1 | Gland, Starboard Side |
Downloads & Resources
- BayStar HP4600 Installation Instructions
- BayStar Front Mount Cylinder Installation Instructions
- Dometic Warranty Information
Important Notices
- Do NOT reuse old socket screws. New stainless screws are included in the kit.
- Debris may be present after screw removal—clean inside and around cylinder barrel thoroughly.
- Tee fittings can be oriented to either side as needed. Use Teflon-based sealant and tighten according to instructions
- Does not include Internal, Center Seal.
Installation Overview (not complete)
- Turn steering hard over toward the side being serviced to minimize fluid loss.
- Remove steering lines and fittings from the gland. Clean fitting threads.
- Loosen socket cap screws securing the gland using a 5/32” Allen driver.
- Remove piston and support rod nuts.
- Remove screws and slide gland off the piston rod.
- Lubricate new gland and slide into position using a seal guide.
- Hand-tighten new screws, reinstall hardware, then torque screws to 60 in-lbs.
- Apply Teflon-based sealant to tee fittings and tighten as specified.
- Repeat for opposite side.
- Bleed system according to BayStar Installation Manual #22 (P/N 946410).
Related & Spare Parts
Item | Part Number / Link | Notes |
---|---|---|
BayStar Cylinder Seal Kit (ORB) | HP4601 | For cylinders ending in -3 |
ORB Bleeder Tee Kit | HF4202 | For H cylinders |
Support Rod Kit, Bent | HP6050 | Includes 2 support rods |
Pivot Plate | — | |
Cylinder HC4645H Replacement | HA4640 | |
Cylinder HC4647H Replacement | HA4641 | |
Cylinder HC4648H Replacement | HA4642 | |
Cylinder HC4658H Replacement | HA4643 | |
Hose Kits | [HERE] | Use approved BayStar hose kits |
BayStar Helm Pumps | [HERE] | Compatible helms for system use |
Why Choose the HP4600 Seal Kit?
- OEM-approved replacement for BayStar Compact “H” cylinders
- Includes both end glands, all sealing components, and hardware
- Ideal for servicing NPT-style front mount cylinders
- Ensures continued steering reliability and smooth performance
